KMY3512-GM Product Introduction This keyboard is currently EFT-POS supporting high-end PIN keyboard, in accordance with international standards for security design, with extremely high security protection measures. It is mainly designed in accordance with the PCI4.X security standard. The keyboard adopts imported encryption chip, supports DES and Triple DES encryption, national secret algorithm, unpacking and self-destruction and other multiple security structures. Improve the strength of PINpad against logical and physical attacks.
Professional customization
Can quickly carry out scheme design and product customization according to customer requirements
KMY3512-GM product introduction
This keyboard is currently EFT-POS supporting high-end PIN keyboard, in accordance with international standards for security design, with extremely high security protection measures.
It is mainly designed in accordance with the PCI4.X security standard. The keyboard adopts imported encryption chip, supports DES and Triple DES encryption, national secret algorithm, unpacking and self-destruction and other multiple security structures.
Improve the strength of PINpad against logical and physical attacks. It has passed PCI4.X certification and UnionPay and bank card PIN input device security testing center.
Product performance
1. Environmental adaptability:
● Working temperature: 0°C~+70°C
●Relative humidity: 30%~95%RH
● Storage temperature: -25°C~+100°C
● Relative humidity: 20%~95%RH (no condensation)
● Atmospheric pressure: 60~106 Kpa
2. Mechanical properties
● Keyboard life: > 3,000,000 times per key
● Key pressure: 3-5 N (N)
● Key travel: 1.0mm
● Case material: high-quality silicone + conductive button
● Keyface characters: typography
● Shell material: high-quality engineering ABS fireproof and corrosion-resistant material
● Dimensions:L84.5*W144*H65.5(MM)
● Product weight: 0.3KG
3. Electrical performance:
● Input keyboard: 11 numeric keys, 3 function keys
●Security performance: key and degree of self-destruction, anti-detection, anti-theft
● Cryptographic algorithms: DES and Triple DES, national secret algorithms SM1-SM4
● Processing power: PIN encryption, MAC operation, data encryption/decryption, etc
●Display: Han display screen with backlight, 2 lines and 16 characters
● Compliance with standards: ISO9564, IBM3624, ANAI X9.8, ANSI X9.9, ANSI X9.19
● Protection capability: Sensitive data for power outages is stored for more than 5 years
● Communication interface: standard RS-232 8-bit data bit, 1-bit stop bit, no check digit
●Working power consumption: 1W, DC+5V
4. Software support:
Provide drivers, dynamic libraries, API functions, or controls.
