Number of buttons: 108Working voltage: DC5V±5%Working current: <150mACommunication interface: USB or RS232Key size: ordinary key: 12*12*2.0mm function key: 15*12*2.0mmKey stroke: 0.5mmButton elasticity: 280g±20gKey life: ≥2 millionPanel size: 80*77*1.5mmSize of the whole machine: 80*77*14mmNet
Professional customization
Can quickly carry out scheme design and product customization according to customer requirements
Number of buttons: 108
Working voltage: DC5V±5%
Working current: <150mA
Communication interface: USB or RS232
Key size: ordinary key: 12*12*2.0mm function key: 15*12*2.0mm
Key stroke: 0.5mm
Button elasticity: 280g±20g
Key life: ≥2 million
Panel size: 80*77*1.5mm
Size of the whole machine: 80*77*14mm
Net weight of the product: 0.35Kg
Product gross weight: 0.45Kg
Operating temperature: -20℃~70℃ (relative humidity 20%~85% / atmospheric pressure 60~106Kpa)
Storage temperature: -30℃~85℃ (relative humidity 5%~90%/atmair pressure 60~106Kpa)
Operating system: Window XP, Window 7, Window 8, Linux, Ubuntu, Android
Field of application:
The product is suitable for ATM, CDM, self-service terminal, automatic ticket machine, self-service payment machine, information kiosk terminal, deposit machine and other self-service equipment.
